Classe:Create Tag:Table
Criar uma Table:

(setq myTable (vla-AddTable
(vlax-3d-point pt1)
(+ 3 cnt)
3; numero de colunas columns
0.7 ; altura das linhas
2.5)) ;largura das colunas
; Definir titulo da tabela
(vla-setText mytable 0 0 "Lista de Materiais")
; Definir titulos da colunas
(vla-setText mytable 1 0 "Numero")
(vla-setText mytable 1 1 "Descrição")
(vla-setText mytable 1 2 "Quantidade")
Comment!See all 1 comments
Classe:EffectiveName Properties Selections Tag:Block
Get the block name:

(setq bloco (entsel "\n Seleccione o bloco:"))
(setq vlaxobj (vlax-ename->vla-object (car bloco)));
(setq nome_bloco (vlax-get-property vlaxobj "EffectiveName"))
(princ nome_bloco)
Comment!See all 0 comments

Classe:Properties ObjectName Tag:Polyline
Neste exemplo explico como alternar entre entidades de lisp e entidades activex...

:::seleccionar um conjunto de objectos
(setq sel_eixo (ssget))

:::ir buscar a sua "identificação" activex
(setq my_vlaxobj (vlax-ename->vla-object (ssname sel_eixo 0)))

::: verificar por exemplo o tipo de objecto
(setq my_vlaxobj_name (vlax-get-property my_vlaxobj "ObjectName" ))

::: se for uma poli, continuamos...
(if (= vlaxobj_name "AcDbPolyline")(progn


::: para ter a identificação autolisp usamos

(setq my_lispobj (vlax-vla-object->ename my_vlaxobj))

Ou seja:

vlax-ename->vla-object ...... lisp -> activex
vlax-vla-object->ename ...... activex -> lisp
Comment!See all 0 comments
Classe:center width Modify height activedocument Tag:View/Zoom
Alterar o "view" ou "Zoom":
(setq doc (vlax-get-property (vlax-get-acad-object) "activedocument")) ;documento atual

(setq viewP (vlax-ename->vla-object (tblobjname "view" "nome-da-view"))) ;view que deseja restaurar

(setq avp (vlax-get-property doc "activeviewport")) ;visualização atual

(vlax-put-property avp "center" (vlax-get-property viewP "center"));altera o centro

(vlax-put-property avp "width" (vlax-get-property viewP "width"));altera a largura

(vlax-put-property avp "height" (vlax-get-property viewP "height"));altera a altura

(vlax-put-property doc "activeviewport" avp) ;atualiza a vizualização

Comment!See all 0 comments

Classe:Lists Sub-rotines Tag:
-> ((23 abc)(15 def)(3 ghi)) --> ((3 ghi)(15 def)(23 abc))
-> devolve a mesma lista ordenada pelo indice 0 da sub lista

(defun bs:ord_lst_lst (lst_orig);
(setq lst_ord (vl-sort-i lst_orig(function (lambda (e1 e2)(< (nth 0 e1) (nth 0 e2)) ) ) )); obter a lista ordenada das posições
(setq lst_final (mapcar (function (lambda (e1)(nth e1 lst_orig) )) lst_ord)); criar a lista final usando as posições ordenadas

Comment!See all 0 comments
Classe:Create Tag:Block Circle
Create a new block:

(setq *Desenho* (vla-get-ActiveDocument (vlax-get-Acad-Object)));identificar o desenho
(setq blocol (vla-get-blocks *desenho*)) ;lista de blocos no desenho
(setq new_block (vla-add blocol var_pt "caixa_pente") ); cria um novo bloco de nome caixa pente
(vla-addcircle new_block var_pt 0.5);adicionar um circulo ao block
Comment!See all 0 comments

Classe:Create Sub-rotines Tag:Circle
Create a circle:

(vl-load-com) ; necessário para se usar activex
(setq *ModelSpace* (vla-get-ModelSpace (vla-get-ActiveDocument (vlax-get-Acad-Object)))); tirar a identificação do model activo
(setq pt_temp (list 0 0 0)) ;definir o ponto de inserção
(setq var_pt (bs:lst_array pt_temp )); converter a lista numa variante
(setq circle (vla-addcircle *ModelSpace* var_pt 1)); cria um circulo com 1m de raio no ponto 0,0,0
;######## BASES #######
(defun bs:lst_array (ptsList / arraySpace sArray);-> (x y x y .....) => variante
(setq arraySpace (vlax-make-safearray vlax-vbdouble (cons 0 (- (length ptsList) 1)) ))
(setq sArray (vlax-safearray-fill arraySpace ptsList))
(vlax-make-variant sArray) )

Comment!See all 0 comments
Classe:Modify Color Create Properties Layer Tag:
Manipular LAYERS:
(setq *Desenho* (vla-get-ActiveDocument (vlax-get-Acad-Object)));identificar o desenho
(setq laycol (vla-get-layers *desenho*)) ;lista de layers no desenho
(if (not (tblsearch "layer" "ic_dre_aux")) ; testar se já existe
(progn (setq layobj (vla-add laycol "novo_layer")) ;criar o layer
(vla-put-color layobj 250) ;atribuir uma cor
)) ;_ end of if

(setq lay_orig (vla-get-activelayer *desenho*)) ;tira o layer actual
(vla-put-activelayer *desenho* (vla-item laycol "novo_layer")) ;colocar o novo
(vla-put-activelayer *desenho* lay_orig); Devolver o original
Comment!See all 0 comments

Classe:Modify Layer Create Tag:Text
Create a text:

(setq *ModelSpace* (vla-get-ModelSpace (vla-get-ActiveDocument (vlax-get-Acad-Object))))
(setq pt0 (list 10 10 10))
(setq var_pt (bs:lst_array PT0))
(setq texto (vla-addtext *ModelSpace* "my text" var_pt 2.5))
(vla-put-Alignment texto 13)
(vla-put-TextAlignmentPoint texto var_pt)
(vla-put-layer texto "new_layer")
(vlax-put-property texto "Rotation" pi)
;######## BASES ########
(defun bs:lst_array (ptsList / arraySpace sArray);-> (x y x y .....) => Variante
(setq arraySpace (vlax-make-safearray vlax-vbdouble (cons 0 (- (length ptsList) 1)) )) (
setq sArray (vlax-safearray-fill arraySpace ptsList)) (vlax-make-variant sArray) )

Comment!See all 0 comments
Classe:Create acHatchPatternTypePr Tag:Hatch
Create a Hatch:

(setq Hatch (vla-AddHatch *ModelSpace* acHatchPatternTypePreDefined "solid" :vlax-True))
(vlax-invoke hatch 'AppendOuterLoop (list pline))
(vla-evaluate hatch)
(vla-delete pline)
Comment!See all 1 comments

Classe:Create Lists Sub-rotines Tag:Polyline
Create a polyline:
(setq *ModelSpace* (vla-get-ModelSpace (vla-get-ActiveDocument (vlax-get-Acad-Object))))
(setq px1 (list 0 0 0))
(setq px2 (list 1 1 0))
(setq var_pt (bs:lst_array (bs:lst_Pt3d->lst_2d (list px1 px2))))
(setq pline (vla-addLightweightPolyline *ModelSpace* var_pt))

;######## BASES #######
(defun bs:lst_array (ptsList / arraySpace sArray);-> (x y x y .....) => Variante
(setq arraySpace (vlax-make-safearray vlax-vbdouble (cons 0 (- (length ptsList) 1)) ))
(setq sArray (vlax-safearray-fill arraySpace ptsList))
(vlax-make-variant sArray) )

(defun bs:lst_Pt3d->lst_2d (lst_pt3d);-> ((xyz) (xyz)...) =>(x y x y..)
(setq polypoints (apply 'append (mapcar 'bs:Pt3d->Pt2d lst_pt3d))))
Comment!See all 0 comments
Classe:Properties Selections Tag:
Algumas coisas básicas...

(vl-load-com) ;Imprescindível para se usar Activex

(setq meu_obj (vlax-ename->vla-object (ssname sel_all index))) ;Tirar a identificação de um objecto de uma selecção...

(vlax-dump-object meu_obj) ;Devolve toda a informação do objecto "meu_obj", importante para sabermos que propriedades podemos manipular!
Comment!See all 0 comments
